- 3072×2048 Full HD resolution
- Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.
- Max. decoding capability: 8 × 1080p@30 fps or 2 × 8 MP@30 fps.
- Max. 160/160/80 Mbps incoming/recording/outgoing bandwidth.
- Supports IP cameras with a resolution up to 12 MP.
- AI by Recorder supports 4-channel SMD Plus.
- AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map.
- Supports EPTZ, and one-click arming and disarming.
System
Main Processor
Industrial-grade processor
Operating System
Embedded Linux
Operating Interface
Web, Local GUI
AI
AI by Recorder
SMD Plus
AI by Camera
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
Perimeter Protection
Perimeter Performance of AI by Camera (Number of Channels)
6 channels
Face Detection
Face Attributes
Gender; age group; glasses; expressions; face mask; beard
Face Detection Performance of AI by Camera (Number of Channels)
6 channels
Face Recognition
Face Recognition Performance of AI by Camera (Number of Channels)
6 channels
SMD Plus
SMD Plus by Recorder
4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera
6 channels
Audio and Video
Access Channel
16 channels
Network Bandwidth
AI disabled: 160 Mbps incoming, 160 Mbps recording and 80 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
Resolution
12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF
Decoding Capability
AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps
Video Output
1 HDMI, 1 VGA Simultaneous: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous: HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
Multi-screen Display
Main Screen: 1/4/8/9/16 Sub Screen: 1/4/8/9/16
Third-party Camera Access
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha
Compression Standard
Video Compression
Smart H.265+; H.265; Smart H.264+; H.264
Audio Compression
G.711a; G.711u; PCM; G726
Network
Network Protocol
HTTP; HTTPS; TCP/IP; IPv4; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports IP camera, DVR, NVS, etc.); P2P; Auto Registration
Mobile Phone Access
iOS; Android
Interoperability
ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK
Browser
Chrome; IE; Safari; Edge; Firefox
Recording Playback
Multi-channel Playback
Up to 16 channels
Record Mode
General, motion detection; intelligent; alarm
Backup Method
USB device and network
Playback Mode
Instant playback, general playback, event playback, tag playback, smart playback
Alarm
General Alarm
Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm
Anomaly Alarm
Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception
Intelligent Alarm
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
Alarm Linkage
Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email
Port
Audio Input
1-channel RCA
Audio Output
1-channel RCA
Alarm Input
NA (2 channels is optional)
Alarm Output
NA (1-channel 12 V 1 A output is optional)
HDD Interface
1 SATA port. up to 20 TB. this limit varies depending on the environment temperature.
USB
2 (2 rear USB 2.0 ports)
HDMI
1
VGA
1
Network Port
1 (10/100/1000 Mbps Ethernet port, RJ-45)
General
Power Supply
12 VDC, 2 A
Power Consumption
Total output of NVR is <10 W(without HDD)
Net Weight
0.45 kg (0.99 lb)
Gross Weight
1.07 kg (2.36 lb)
Product Dimensions
204.6 mm × 206.4 mm × 45.6 mm(8.06″ × 8.12″ × 1.80″) (W × D × H)
Packaging Dimensions
364 mm × 96 mm × 261 mm (14.33″ × 3.78″ × 10.26″) (W × D × H)
Operating Temperature
–10 °C to +55 °C (14 °F to +131 °F)
Storage Temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity
10%–93% (RH), non-condensing
Installation
Rack or desktop
Certifications
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
