Specification

• General

• Weight0.4 kg (0.88 lb)
• Installation Mode Desk-Mounted, Wall-Mounted, Ceiling Mounting
• Working Temperature0 °C to 40 °C (32 °F to 104 °F)
• Working Humidity5% to 95% (no condensation)
• Storage Temperature-40 °C to 70 °C (-40 °F to 158 °F)
• Storage Humidity5% to 95% (no condensation)
• Product Dimensions (W × H × D)220 mm × 220 mm × 35 mm (8.66” × 8.66” × 1.37”)
• Packing List1200 M Access Point ×1,Screw Pack × 1,Quick Start Guide ×1,Regulatory Compliance and Safety Information × 1
• Power Consumption Max. 11.35 W

• WLAN Parameters

• Maximum Number of Clients256
• Recommended Number of Clients80
• Maximum Number of SSIDs8
• Working Frequency Band radio 1: 5G(11a/an/ac), radio 2: 2.4G(11b/g/gn)
• Wi-Fi Standards Wi-Fi 5
• Wi-Fi Speed2.4 G: 300 Mbps,5 G: 867 Mbps
• Spatial Streams2.4 GHz, 2 × 2 , MU-MIMO, 5 GHz, 2 ×2 , MU-MIMO
• Channel Width2.4 GHz: Auto/20 /40 MHz,5 GHz: Auto/20 /40 /80/MHz
• Number of Antennas2.4 GHz：2；5 GHz：2
• Antenna Type Built-in omnidirectional antennas
• Antenna Gain2.4 GHz: 3 dBi,5 GHz: 4 dBi
• Transmit Power20 dBm
• Modulation TechnologyOFDM：BPSK@6/9Mbp、QPSK@12/18Mbps、16-QAM@24Mbps、64-QAM@48/54Mbps; DSSS：DBPSK@1Mbps、DQPSK@2Mbps、CCK@5.5/11Mbps; MIMO-OFDM （11n）：MCS 0-15; MIMO-OFDM （11ac）：MCS 0-9

• Software Specifications

• WLAN SecurityWAP-PSK,WAP2-PSK,WPA-WAP2-PSK,Blocklist & Allow list, Support Multiple encryption key triggered dynamic unicast/multicast key update, Support Open system/shared key authentication, Support wireless endpoint access, Support SSID and VLAN binding, Support 802.11i
• Management & Maintenance Centralized AC management
• Version Upgrade upgrade on Web

• Hardware Specifications

• Interface1 × Gigabit RJ45 uplink port
• Power Supply IEEE 802.3af/at POE,12 VDC 1.5 A
• LED Indicator Yellow/green/blue for different working states, flashing mode
• Reset Button Hardware Resetting Button

• Approval

• EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
• Safety CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017),UL (UL 60950-1)
• Chemistry CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
• Radio EN 301 893,EN 300 440,EN 62311,EN 301 489-3,EN 301 489-17
