- 5MP high quality image
- TVI/AHD/CVI/CVBS
- IR-cut filter with auto switch (ICR)
- Supports 180° horizontal flip, 180° vertical flip
- OSD configuration menu, easy to operate
- IP67 waterproof and dustproof design, high reliability
- OSD configuration menu in 11 languages
Model UAC-B115-F28 UAC-B115-F40 Sensor Pixel 5MP Size 1/2.7″ Minimum illumination 0.02lux(F2.0, AGC ON)
0 lux (IR on)Lens Lens 2.8mm 4.0mm Lens mount M12 Angle of view H: 102.2° V: 53.9° D: 124.8° H: 82.9° V: 46.1° D: 100.0° Illuminator Illuminator One IR illuminator Illumination distance 20m Lifetime ≥60,000 hours Video Resolution 5MP@25fps: 2880(H)×1620(V); 5MP@20fps: 2592(H)×1944(V); 5MP@12.5fps: 2592(H)×1944(V)
4MP: 2560(H)×1440(V)
1080P: 1920(H)×1080(V)Frame rate TVI: 5MP@20fps, 5MP@12.5fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
CVI: 5MP@25fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
CVBS: PAL, NTSCShutter time PAL: 1/25s-1/50000s
NTSC: 1/30s–1/50000sImage Exposure mode 4 modes: Global (default), BLC, HLC, DWDR Day/Night 3 modes: Auto (default), Day, Night Digital noise reduction 2D White balance Two modes: Auto (default), Manual WDR DWDR Smart IR Support Flip Supports 180° horizontal flip, 180° vertical flip. Interface Power 5.5mm power interface Video output BNC, supports TVI/AHD/CVI/CVBS Operating environment Temperature -30℃ to 60℃(-22℉ to 140℉) Humidity ≤95% (RH, non-condensing) Surge protection 4KV Ingress protection IP67 General Power DC12V (±25%), with reverse polarity protection and surge protection, Max 3.6W Mount 3D bracket supplied, surface mount (default), optional backbox, pole mount bracket Dimensions 142mm*63mm*65mm (L*W*H) Material Plastic Weight 135g(0.30lb) Certification CB, CE, FCC
- +92 300 1114067
- info@aytech.pk
- Lahore, Panjab, Pakistan
