Camera

• Image Sensor1/1.8″ progressive scan CMOS
• Max. Resolution2560 × 1440
• Min. Illumination Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.0005 Lux @ (F1.5, AGC ON), 0 Lux with IR
• Shutter Speed1/1 s to 1/30,000 s
• Day & Night IR cut filter
• Zoom45 × optical, 16 × digital
• Slow Shutter Yes

• Lens

• Focal Length5.9 to 265.5 mm
• FOV

  Horizontal field of view：60.2° to 1.7°

  Vertical field of view：35.2° to 1°

  Diagonal field of view：67.4° to 1.8 °

• Focus Auto, semi-auto, manual, rapid focus
• Aperture Max. F1.5
• Zoom Speed Approx. 8.5 s

• Illuminator
• Supplement Light Type IR
• Supplement Light Range Up to 300 m

• PTZ

• Movement Range (Pan)360°
• Movement Range (Tilt)-15° to 90° (auto flip)
• Pan Speed Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
• Tilt Speed Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
• Proportional Pan Yes
• Presets300
• Preset Freezing Yes
• Patrol Scan8 patrols, up to 32 presets for each patrol
• Pattern Scan4 pattern scans, record time over 10 minutes for each scan
• Park Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
• 3D Positioning Yes
• PTZ Status Display Yes
• Scheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
• Power-off Memory Yes

• Video

• Main Stream

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720),

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288);

  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

• Third Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288);

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264

  Sub-stream: H.265/H.264/MJPEG

  Third stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 16384 Kbps
• H.264 Type Baseline profile, main profile, high profile
• H.265 Type Main profile
• Scalable Video Coding (SVC)H.264 and H.265 encoding
• Region of Interest (ROI)8 fixed regions for each stream

• Audio

• Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
• Audio Bit RateMP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps

• Network

• ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QOS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPOE, Bonjour
• API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
• User/Host Up to 32 users. 3 user levels: administrator, operator, and user
• Security Password protection, complicated password, HTTPS encryption, 802.1X authentication, watermark, IP address filter, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address)
• Network Storage NAS (NFS, SMB/CIFS), ANR
• ClientiVMS-4200, HIK-Central, HIK-Connect
• Web BrowserIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

• Image

• Image Parameters Switch Yes
• Image Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
• Wide Dynamic Range (WDR)120 dB
• SNR≥ 52 dB
• Defog Digital defog
• Image Stabilization EIS (Built-in gyroscope to improve EIS performance)
• Image Enhancement BLC, HLC, 3D DNR
• Privacy Mask24 programmable polygon privacy masks, mask color or mosaic configurable
• Regional Focus Yes
• Regional Exposure Yes

• Interface

• Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
• On-board Storage Built-in memory card slot, support microSD/micro SDHC/micro SDXC card, up to 256 GB
• Audio1 input (line in), max. input amplitude: 2-2.4 VPP, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
• Alarm7 inputs, 2 outputs
• RS-4851 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

• Event

• Basic Event Motion detection, video tampering alarm, exception, alarm input and output
• Smart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
• Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)
• Smart Tracking Manual tracking, auto-tracking

• Deep Learning Function
• Face Capture

  Detects up to 15 faces simultaneously.

  Supports detecting, capturing, grading, selecting of face in motion, and outputs the best face picture

• General

• Power

  24 VAC, 3.0 A, 50/60 Hz & Hi-POE, 42.5 to 57 VDC, 1.41 A

  (Max. 40 W, includes max. 16 W for IR and max. 10 W for heater)

• Dimension Ø 226 mm × 354 mm (Ø 8.90″ × 13.94″)
• Weight Approx. 5.0 kg (11.02 lb.)
• General Function Mirror, password protection
• Operating Condition-40 °C to 70 °C (-40 °F to 158 °F). Humidity 95% or less (non-condensing)

• Approval

• EMC

  FCC SDOC (47 CFR Part 15, Subpart B);

  CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);

  RCM (AS/NZS CISPR 32: 2015);

  IC VOC (ICES-003: Issue 6, 2019);

  KC (KN 32: 2015, KN 35: 2015)

• Safety

  UL (UL 62368-1)

  CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);

  CE-LVD (EN 62368-1:2014+A11:2017),

  BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);

  LOA (SANS IEC60950-1)

• Environment

  CE-RoHS (2011/65/EU); WEEE (2012/19/EU);

  Reach (Regulation (EC) No 1907/2006)

• ProtectionIP66 (IEC 60529-2013), Lightning Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to G n d, ±3kV Line to Line, IEC61000-4-5
