Camera

• Image Sensor1/1.8″ progressive scan CMOS
• Min. Illumination Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @ (F1.2，AGC ON), 0 Lux with IR
• Shutter Speed1/1 s to 1/30,000 s
• Slow Shutter Yes
• Day & Night IR cut filter
• Zoom42x optical, 16x digital
• Max. Resolution2560 × 1440

• Lens

• Focus Auto, semi-auto, manual, rapid focus
• Focal Length6.0 mm to 252 mm
• Zoom Speed Approx. 4.5 s
• FOV

  Horizontal field of view: 56.6° to 1.7° (wide-tele),

  Vertical field of view: 33.7° to 0.9° (wide-tele),

  Diagonal field of view: 63.4° to 1.9° (wide-tele)

• Aperture Max. F1.2

• Illuminator
• Supplement Light Type IR
• Supplement Light Range up to 400 m
• Smart Supplement Light Yes

• PTZ

• Movement Range (Pan)360°，Smart Pan-Tilt Correction
• Movement Range (Tilt)-20° to 90° (auto flip)，Smart Pan-Tilt Correction
• Pan Speed Pan speed: configurable from 0.1° to 210°/s; preset speed: 280°/s
• Tilt Speed Tilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s
• Proportional Pan Yes
• Presets300
• Patrol Scan8 patrols, up to 32 presets for each patrol
• Pattern Scan4 pattern scans, record time over 10 minutes for each scan
• Power-off  Memory Yes
• Park Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
• 3D Positioning Yes
• PTZ Status Display Yes
• Preset Freezing Yes
• Scheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

• Video

• Main Stream

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720);

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

• Third Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264

  Sub-stream: H.265/H.264/MJPEG

  Third stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 16384 Kbps
• H.264 TypeBaseline Profile/Main Profile/High Profile
• H.265 TypeMain Profile
• Scalable Video Coding (SVC)H.264 and H.265 encoding
• Region of Interest (ROI)8 fixed regions for each stream

• Audio

• Audio CompressionG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM，AAC_LC
• Audio Bit Rate64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)16 Kbps to 64 Kbps(AAC_LC)

• Network

• Network Storage NAS (NFS, SMB/ CIFS), ANR
• ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, QOS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPOE, Bonjour, Web Socket, Web Sockets
• APIISUP, ISAPI, HIKVISION SDK, Open Network Video Interface (Profile S, Profile G, Profile T)，OTAP
• Simultaneous Live View Up to 20 channels
• User/Host Up to 32 users 3 user levels: administrator, operator, and user
• Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)
• Client HIK-Central, iVMS-4200, HIK-Connect
• Web BrowserIE11, Chrome 57.0+, Firefox 52.0+, Safari 11+

• Image

• Day/Night Switch Day, night, auto, scheduled-switch
• Image Enhancement BLC, HLC, 3D DNR
• Wide Dynamic Range (WDR)140 dB
• Defog Yes
• Image Stabilization EIS (Built-in gyroscope to improve EIS performance)
• Regional Exposure Yes
• Regional Focus Yes
• Image Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
• Image Parameters Switch Yes
• Privacy Mask Up to 24 masks, mosaic mask, mask color configurable, rectangle region
• SNR≥ 52 dB

• Interface

• Video Output1.0 V[p-p]/75 Ω, PAL, NTSC, BNC connector
• Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
• On-board Storage Built-in memory card slot, support microSD/micro SDHC / micro SDXC cards, up to 256 GB
• Alarm7 inputs, 2 outputs
• Audio1 input (line in), max. input amplitude: 2-2.4 VPP, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
• RS-485Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive

• Event

• Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, and PTZ actions (such as preset, patrol scan, pattern scan)
• Basic Event motion detection, video tampering alarm, alarm input, alarm output, exception
• Smart Event Line crossing detection, region entrance detection, unattended baggage detection, object removal detection, intrusion detection, region exiting detection, vandal-proof alarm, audio exception detection
• Smart Tracking Manual tracking, auto-tracking

• Deep Learning Function
• Face Capture Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face
• Face Comparison Yes
• Perimeter Protection

  Line crossing, intrusion, region entrance, region exiting

  Support alarm triggering by specified target types (human and vehicle)

• Road Traffic and Vehicle Detection
• Road Traffic Support vehicle detection (license plate number, vehicle model, and vehicle color recognition)

• General

• Operating Condition Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95%
• Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
• Power Consumption and Current24 VAC (Max. 62 W, including max. 12 W for IR and max. 8 W for heater), PoE 802.3 bt (Max. 51 W, including max. 12 W for IR and max. 8 W for heater)
• Wiper Yes. Rain-sensing auto control
• Dimension Ø 267 mm × 430 mm (Ø 10.51″ × 16.93″)
• Weight Approx. 9.6 kg (21.16 lb.)

• Approval

• EMC

  FCC SDOC (47 CFR Part 15, Subpart B);

  CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);

  RCM (AS/NZS CISPR 32: 2015);

  IC VOC (ICES-003: Issue 6, 2019);

  KC (KN 32: 2015, KN 35: 2015)

• Safety

  UL (UL 62368-1)

  CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);

  CE-LVD (EN 62368-1:2014+A11:2017),

  BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);

  LOA (SANS IEC60950-1)

• Environment

  CE-RoHS (2011/65/EU); WEEE (2012/19/EU);

  Reach (Regulation (EC) No 1907/2006)

• ProtectionIP67 Standard, IK10 (IEC 62262:2002), 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
