Specification

• Intelligent Analytics

• AI by NVR Facial recognition, perimeter protection, motion detection 2.0
• AI by Camera Facial recognition, perimeter protection, video structuralization, throwing objects from building, motion detection 2.0, ANPR, people counting, VCA
• Engine1, engine mode is adjustable

• Facial Recognition

• Facial Detection and Analytics Face picture comparison, human face capture, face picture search
• Face Picture Library Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 1 GB)
• Face Picture Comparison (Captured from Camera)8-ch
• Facial Detection and Analytics Performance4-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)

• Motion Detection 2.0

• By NVR All channels for Hikvision cameras
• By Camera All channels

• Perimeter Protection

• By NVR

  4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm;

  Up to 12 rules in total

• By Camera All channels

• ANPR

• By Camera All channels
• Vehicle Attributes Plate number, license plate color, license plate type
• Plate Attributes Vehicle brand, vehicle color, vehicle type

• Video and Audio

• IP Video Input64-ch
• Incoming Bandwidth384 Mbps
• Outgoing Bandwidth256 Mbps
• HDMI 1 Output4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
• HDMI 2 Output4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
• VGA 1 Output1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
• VGA 2 Output1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
• Video Output ModeHDMI1/VGA1 simultaneous output, HDMI2/VGA2 simultaneous output,HDMI1/HDMI2 independent output
• CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
• Audio Output2-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)

• Decoding

• Decoding FormatH.265+/H.265/H.264+/H.264
• Recording Resolution

  32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF

  *: The NVR supports up to 4-ch 32 MP/24 MP IP video inputs.

• Synchronous Playback16-ch
• Live View Window Division1/2/4/6/8/9/16/25/32/36/64
• Aux Port Window Division1/2/4/6/8/9/16/25/32/36
• Decoding Capability

  Enable AI by NVR: 20-ch@1080p (30 fps)

  Disable AI by NVR: 32-ch@1080p (30 fps)

• Dual-Stream Recording Support
• Stream Type Video, Video & Audio
• Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM

• Network

• Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
• Remote Connection128
• Network Protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP
• APIONVIF (profile S/G); SDK; ISAPI
• Compatible BrowserIE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
• Camera Access Protocol ONVIF(Version 2.5), RTSP

• RAID

• RAID TypeRAID0, RAID1, RAID5, RAID6, RAID10 Support global hot spare

• Auxiliary Interface

• Serial Interface1 RS-485 (full-duplex), 1 RS-232
• SATA8 SATA interfaces
• Capacity Up to 16 TB capacity for each disk
• eSATA1 e SATA interface
• Alarm In/Out16/9
• USB Interface Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0

• General

• GUI Language English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian, Hebrew
• Power Supply100 to 240 VAC, 50 to 60 Hz
• Consumption≤ 30 W (without HDD)
• Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity10% to 90%
• Chassis2U chassis
• Dimension (W × D × H)440 × 457 × 94 mm ( 17.4″× 18.0″ × 3.7″)
• Weight≤ 7.1 kg (without HDD, 15.7 lb.)

• Certification

• Obtained Certification CE, CB, REACH, WEEE, UKCA, LOA
• CEEN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
