DS-K1T201

HIKVISION K1T201 Pro Series Fingerprint Terminal

Category: Times & Attendances Mechines

Description
Reviews (0)

Pro Series Fingerprint Terminal

Fingerprint Access Control Terminal
2.8-inch LCD display screen
5000 fingerprints, 100,000 cards（EM card＿ 300,000 events storage
Communication via TCP/TP and Wi-Fi
RS-485 and Wiegand interface
ISUP5.0、ISAPI

Available models:

DS-K1T201AEF

Product Data

Display
Screen size2.8-inch
Type Display screen

Network
Wired network100 M/1000 M self-adaptive

Interface
Network interface1
Lock control1
Exit button1
Door contact input1
Alarm input2
Alarm output1
TAMPER1
RS-4851
Wiegand1
USB1

Authentication
Card type EM card
Card reading frequency125 kHz

General
Power supply12 VDC/2 A
Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
Working humidity10% to 90%
Dimensions137 mm x 142 mm x 35 mm (5.4″ × 5.6″ × 1.4″)

,

Screen size2.8-inch
Type Display screen

,

Wired network100 M/1000 M self-adaptive

,

Network interface1
Lock control1
Exit button1
Door contact input1
Alarm input2
Alarm output1
TAMPER1
RS-4851
Wiegand1
USB1

,

Card type EM card
Card reading frequency125 kHz

,

Power supply12 VDC/2 A
Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
Working humidity10% to 90%
Dimensions137 mm x 142 mm x 35 mm (5.4” × 5.6” × 1.4”)
